Using MetricFlow queries in dbt models

Written by Silja Märdla, Senior Analytics Engineer at Bolt.

As users of dbt_metrics know, the dbt_metrics package will be deprecated and replaced with MetricFlow. Together with this step, the metrics.calculate() macro from the dbt_metrics package will also be deprecated. The current suggestion is to use the --explain parameter in the MetricFlow query to compile the SQL code that you can then paste into your dbt model code.

Because I believe in the power of the Semantic Layer and metrics, I’ve been on a journey to implement and re-implement some metrics for Bolt.

Here is a summary of how the MetricFlow queries can currently be used when you’re on dbt core instead of the cloud.

Before sharing the hacky workaround process that I have come up with, I’d like to summarise some pain points we feel:

• --explain provides a fully compiled query, no {{ref()}} macros that would keep the lineage intact (issue, thread).
• There is no way to (even manually) define the dependency of data marts on semantic models and metrics (thread).
• There is no straightforward functionality to make sure partition keys are filtered (thread).

That said, here’s what I like about MetricFlow queries (compared to the dbt_metrics functionality):

• There is no need to build extra wide fact tables to support the metrics queries (we can simply get the dimension values from dimension tables).
• Users can use the mf query functionality to construct queries for their ad hoc analysis.

So, here’s a copy of an internal document written to guide the creation of data marts using MetricFlow queries:

1. Define semantic models and metrics in yml files;
2. List the available metrics using mf list metrics;
3. Create a comma-separated list of the metrics you wish to include in your model;
4. Construct your MetricFlow metrics query in the format

where metric1, metric2 and metric3 are metric names. No spaces are allowed in the list of metric names;

1. Test your metrics query by running the same MetricFlow command without –explain and reasonable date limits;
2. Add the metrics query to the beginning of your model inside a SQL comment /* ... */;
3. Run the MetricFlow query to compile the model SQL code. It will be printed in the terminal output by default. For long queries (1000+ lines), it helps to send the terminal output to a file:

Notice the beginning of the file will need to be cleaned up.

• Place the compiled SQL query in your model;
• If you need to rename any of the output columns (typically, the dimensions need renaming), place the compiled SQL inside

and modify the SELECT * to do the renaming;

• Construct a full list of fact tables your metrics rely on (either from metrics definitions or by reviewing the list of FROM statements in the output query);
• Add the list to the beginning of your model inside a SQL comment /* ... */;
• Find and replace each occurrence of

with

where table_name=dbt_model_name. You can omit the dbt_project name and use

but it’s better to be explicit.

This will ensure the model has references to its upstream models and the dependencies in the dbt data lineage graph.

• Find and replace each occurrence of

with

This will replace the placeholder data interval start and end dates with jinja variables to use the data_interval_start and data_interval_end passed by Airflow. Input tables are partitioned by date; this is how we make sure we filter according to the data interval being processed.

• Compile the dbt project;
• Review the compiled SQL code for the dbt model in your target folder;
• Test your model by running the dbt model.
